Technical Specification

• Operating panel : Touch screen ( HDMI control ) 7 inch
• PLC base operating program Relay card with 8 channel
• SMPS power supply 24v DC I 5 amp
• Patient data storage inbuilt control
• Dosimetry Time: According to Uv Radiation Dosimeter
• Selection of Dosage : Dosimetry and time priority
• PLC ( programable logic control ) base Over Dosage protection
• 24 Tubes are imported from philips holland NB UVB - OuRS lOOwatt
• Unit cabinet made of high quality mild steel with 7 step powder coating process.
• Patient safety Security system
• Imported mirror type reflectors ensure maximum irradiation
• Spike guard protection
• MCB (Main Circuit Breaker) ensure max safety for the patient
• ELCB (Earth Leakage Circuit Breaker) for patient safety
• UV protected glass can be provided for patient operator
• Fully insulated circuit base
• Cooling fans provided
• Open top unit enables maximum ventilation

• Psoriasis
• Vitiligo
• Mycosis Fungoides
• Atopic Dermatitis
• Parapsoriasis
• Lichen Planus

Optional Features

• Radiation: Both Narow Band UVB-3llnm UVA32O-360nm.
• Computerized connectivity with software
• mobile connectivity by application
• Patient History storage in memory
• Internet connectivity
• pendrive Attachment for patient History record.
• Whole body UV therapy are also available with square Round shape
• UV Therapy with different combination (UVA NB UVB) can be provided as per your choice up to 48 tubes.
